VOH stands for Voltage Out High and refers to the highest voltage a digital circuit can emit as an output from its logic state. The rate of increase in output voltage produced by an active device is usually measured at a certain amount of time, and that rate of increase becomes VOH.

Digital circuits are made up of logical gates (AND, OR, NOT), which interact with each other to produce an output. When a gate is activated, its output voltage increases to the level established by VOH until it reaches a logical high state. If the correct VOH level isn't given, the circuit may not be able to operate properly or achieve its desired logic levels.

The value of VOH is determined by the type and speed/performance parameters of a given digital circuit. For example, higher-speed circuits require higher levels of voltage in order to operate properly so they will have higher values of VOH than slower circuits.

In addition to being important for digital circuits, higher values of VOH are often required in AC motor control and power supply design in order to provide sufficient electrical energy for these applications. By increasing the voltage out high, more power is available when needed as input or output will alloow proper operation conditions.

A multimeter connected directly to your circuit's output pin can be used to measure and confirm the current Voltage Out High (VOH) level you are receiving from your circuit or application. It’s important to note that accurate measurements must be taken before any changes are made so that you can compare those readings against future readings after modifications have been made.
