What is STEM?

Scanning Transmission Electron Microscopy (STEM) is a type of transmission electron microscopy that combines scanning electron microscopy with transmission electron microscopy. By combining these two methods, it can produce high quality images of nanometer-scale structures with sub-nanometer resolution. The technique involves passing an electron beam through a sample at different angles to form an image based on the transmitted electrons' intensity profile. This allows for more accurate imaging than either method can provide alone. High resolution images generated from STEM can be used to study materials’ chemical composition, atomic arrangement, crystalline structure and even individual atoms or molecules within them.

How does STEM work?

The basic principle behind STEM is very simple: An electron beam is passed through a sample at various angles which allows for fine imaging of its properties based on the intensity profile of transmitted electrons at each angle. During this process, signals are collected from each point in the sample that are then converted into digital images by computers equipped with image processing software specifically designed for this purpose. Additionally, detectors measure the energy spectrum of transmitted electrons which helps us determine the chemical nature of samples and their crystalline structure at atomic scales.

Advantages of STEM

The main advantage of using Scanning Transmission Electron Microscopy (STEM) over other conventional techniques is its high resolution capabilities combined with relatively low cost compared to other traditional methods like X-ray diffraction or Scanning Tunneling Microscopy (STM). Also due to its sensitivity towards small atomic features such as lattice defects or grain boundaries it can be used to characterize materials down to the nanoscale level; good enough for most research purposes where high accuracy is required. Furthermore, it can also help scientists identify unknown materials through analysis of elemental maps which makes it ideal for characterizing complex alloys or composites where identifying individual components may prove difficult otherwise without any further sampling procedures.

Applications Of STEM

The use cases for Scanning Transmission Electron Microscopy (STEM) are broad and diverse ranging from failure analysis in industrial products such as electronic circuits or automotive parts to characterization of new materials being developed in research labs across various disciplines like biotechnology and medicine among many others. Furthermore it has been used extensively in studies involving complex mineralogical phases in geological processes or biological specimens like plant tissues where imaging down to cellular levels could prove invaluable even allowing observation down to individual molecules present in those samples depending on the required resolution needed. In addition, stem's ability to generate elemental maps not only helps us better understand certain properties but also allow us identification and differentiation between similar elements without any additional sampling procedures making it an invaluable tool when dealing with highly complex systems composed by dozens if not hundreds different elements.
