OTF stands for Optical Transfer Function. It is a measure of the performance of an optical system, often used to evaluate the image quality of lenses or imaging systems.

The OTF measures the effectiveness with which an optical system can transfer light from its input to its output. It essentially characterizes how much light energy is transferred from one point on the input plane to its corresponding point on the output plane.

The OTF is calculated by comparing the amplitude and phase information between two points on the object and image planes. This is done by analyzing how much light energy is being transferred between them, taking into account all aberrations that may be present in the system.

An OTF graph will typically feature a set of lines representing increasing frequencies, each with a different intensity value associated with it. For example, if you consider a perfect lens with zero distortion then all frequencies would appear as solid lines with value 1 (perfect transmission). On the other hand, in case of some aberration present in the system then some frequency components will appear as dotted or dashed lines with values lower than 1 (imperfect transmission).

By graphing out the transfer function we are able to quickly and accurately assess what types of aberrations are present in a particular optical system. This allows us to identify any areas that require improvement – either during design or after manufacture – in order to achieve optimum performance from our optics.

The most common application is for evaluating lens performance; such as zoom lenses or camera sensors. Additionally, it can also be used when developing new imaging systems or assessing existing ones in order to determine where improvements are needed in order to optimize their performance.

Using an analytical approach you can compare your design parameters against standard parameters found within literature and/or industry standards/specifications – e.g., ISO 9001 – for each parameter type (aberration) using curves plotting average acceptable values against frequency values obtained from your data points collected directly from testing your optics during manufacturing process or before delivery/ex-factory tests..

Yes - depending on your level of experience and knowledge about optics you can certainly calculate your own MTF curves for various components requirements such as ITO coating thickness uniformity requirements etc - while comparison of obtained results take place side-by-side against reference literature standards /specifications /target goals previously established for specific project purposes.

There are several variables that should be taken into consideration when constructing your own curve; including but not limited to focal length, aperture size, wavefront aberration and distortion levels, wavelength range etc... You should consult professional help if you feel unsure about any aspect.
